Power source: 90-240V/AC
Power frequency: 50/60Hz
Rated load:
300W Max.tungsten(cos¦Õ=1)(100-130V/AC)
500W Max.tungsten(cos¦Õ=1)(220-240V/AC)
Detection angle:>140¡ã
Light-control:3LUX~1000LUX (adjustable)
Time setting:10¡À3sec~10¡À2min(adjustable)
Sound control sensitivity:30db~90db(adjustable)
Detection range:10¡À2m Max (22¡ãC)
Installation height:0.4m~1.8m
Power consumption:0.45W (static 0.1W)
Detection motion speed:0.6~1.5m/s
Working humidity:<93%RH
Working temperature:-10~+40¡ãC
This product is a new energy-saving lighting switch, it adopts high sensitivity detector, MCU control, controllable Silicon and SMT; It gathers automatic, convenient, safety and practical functions; The wide detection range is made up of the up and down, left and right service field; It utilizes the infrared energy from Human Body as the control-signal source, When one enters the detection field, it will start the controlled load; It can identify day and night automatically; Its installation is convenient and its range is wide; It has the functions of the power indication and the detection indication.
